Block Substitution

The graphical image of a Block can be substituted with another image object.

Firstly, ensure the drawing is processed with Blocks converted into Space Objects, below as a sample,the audiovisual block is being processed in CADViewer.


Conversion parameters

		cadviewer.cvjs_conversion_clearAXconversionParameters();

		// process blocks with a given name, in this case "audiovisual"
		cadviewer.cvjs_conversion_addAXconversionParameter("blockname", "audiovisual");

		// process all invisible attributes in the block
		cadviewer.cvjs_conversion_addAXconversionParameter("ia", "");

		// open the modelspace
		cadviewer.cvjs_conversion_addAXconversionParameter("model", "");

		// Load file - needs the svg div name and name and path of file to load
		cadviewer.cvjs_LoadDrawing("floorPlan", FileName );

Secondly, make a loop over all instances of the block and substitute the image, using the API method cvjs_replaceSpaceObjectPathWithImage() :

Image Substitution/Overlay


function AudioVisual(){

  var spaceObjectIds = cadviewer.cvjs_getSpaceObjectIdList();
      console.log(" IDs:"+spaceObjectIds.length);

  var id;

    for (var spc in spaceObjectIds){
        id = spaceObjectIds[spc];
        console.log("AudioVisual id="+id+" spc:"+spc);
      cadviewer.cvjs_replaceSpaceObjectPathWithImage("floorPlan", id, loadSpaceImage_Location);
    }

  }

Before Block Substitution

Blocks

After Block Substitution

Blocks
